The OPTI-TRAP™ is a bi-directional trap cartridge system that can be used individually or in series for sample concentration and purification.
The Capillary holder assembly is PEEK. The OPTI-TRAP Capillary cartridge used with this holder uses a PCTFE insert with titanium frits.
The OPTI-TRAP system features low back pressure and may be loaded and eluted manually with a syringe or used on-line when plumbed into the sample injection valve. The bi-directional OPTI-TRAP cartridge supports flushing and bed regeneration.
The OPTI-TRAP system is rated hand-tight for use up to 1,500 psi (100 bar).
Custom packing is available for OPTI-TRAP cartridges upon request.
| OPTI-TRAP Cartridge | Holder | Part Number |
|---|---|---|
| Capillary — 0.5 µL | Capillary Loop Trap Holder | 10-02-04808 |
This holder is compatible with the OPTI-TRAP™ Capillary 0.5 µL cartridge.
| OPTI-TRAP Cartridge | Compatible Holder | Part Number |
|---|---|---|
| Capillary — 0.5 µL | Capillary Loop Trap Holder | 10-02-04808 |
For OPTI-TRAP cartridge options, see OPTI-TRAP Cartridges.
The OPTI-TRAP Manual Holder Kit and the Micro/Macro Loop Trap Holder are separate OPTI-TRAP holder products.
For broader physical-fit information, see the Trap Compatibility & Holder Reference.
For help with component or configuration questions, contact Optimize Technologies.
| SKU | 10-02-04808 |
|---|---|
| Part Number | 10-02-04808 |
| Compatible Cartridge | OPTI-TRAP Capillary — 0.5 µL |
| OPTI-TRAP System Pressure Rating | Rated hand-tight for use up to 1,500 psi (100 bar) |
| Included | Fittings and tubing |
Part #10-03328-ES, 10-03328-TA, 10-03328-xx..., 10-03324-ES, 10-03324-xx..., 10-03317-ES, 10-03317-TA, 10-03317-xx..., 10-03229-ES, 10-03229-TA, 10-03229-xx..., 10-03233-ES, 10-03233-TA, 10-03233-xx...
